Production Introduction
WalthMac ULTRAMAC series
 | high accuracy: highest precision up to 0.001mm Multi-layer pipe measurement (optional). be suitable gas/ water supply pipe, and medical catheter production lines. reduce quality risk complied with EU standard |
PRODUCT DETAILS
Our products have been tested in the market, and our online thickness gauge products occupy 60% of the domestic market. It has a 100% market share in key energy and Marine pipe phenology products. All this shows that our product quality and service has been recognized by everyone, also shows that we have strong technical ability.
 | Whole Process On-line Measurement Our system has an unmatched advantage over the traditional hand-held device for measuring products after they come off the extruder line. It continuously measures products during the production process, and when problems are found, adjustments can be made without waiting for the pipe to come off the extruder line. Save raw materials. |
identification and marking of defective pipes The system will automatically record the pipe quality in the whole production process, and can call out the quality report of the corresponding period when the product has problems, so as to find and correct the production line problems in time. The customer's printer can print the label on the pipe. Once the problem of pipe is found, we only need to find the pipe with the corresponding number in the warehouse to avoid quality risk. |  |
 | EU Standard All products of WalthMac are in line with EU standard, quality assured. Walthmac insist that product is a work of art, and be strict with every detail. Choosing Walthmac means choosing high standards products. |
OUR SERVICE
APPLICATION AREA
The system is widely used in the quality inspection of various single/multi-layer plastic pipes, such as: gas pipe, water supply pipe, medical catheter, brake pipe, oil pipe, intervention catheter, etc.
Technical parameter
The Applications | Gas pipe ,water pipe ,car catheter medical catheter ,ocean pipe etc |
The Application for material | Plastic pipes, rubber pipe |
Control unit | WalthMac DATASE IOOOR ultrasonic measurement control system |
Display unit | 12"/ 15"/21 "true color of touch screen (Optional) |
The Max. measuring precision | 0.001 mm |
The OD measuring range | 0.25-1600mrn |
Power consumption | (+Display power) |
Operation voltage | (Customized power avl upon the request) |
PRODUCT CONGIGURATION
Model | Configuration | The OD measuring range |
ULTRAMAC 063-4T | 4 probes | 3.75-63mm |
ULTRAMAC 063-4T/2 (Twin-tube measurement) | 8 probes | 3.75-63mm |
ULTRAMAC 160-4T | 4 probes | 32-160mm |
ULTRAMAC 160-8T | 8 probes | 32-160mm |
ULTRAMAC 250-4T | 4 probes | 90-250mm |
ULTRAMAC 250-8T | 8 probes | 90-250mm |
DELIVER SHIPPING AND SERVING
The machine before delivery, will pass strict production test, to ensure the reliable quality.
All products are packed safely before delivery to ensure that the goods will not be damaged, scratched and other conditions during transportation.
We offer many modes of transportation including sea and air, international mainstream freight companies are supported.
FAQ
Q1. your terms of packing?
A: Generally, we pack our ultrasonic plastic pipe measuring machine in wooden cases.
Q2. What is your terms of delivery?
A:EXW,FOB,CFR,CIF
Q3. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q4.What is your items of payment?
A:T/T or some other payment methods. We'll show you the photos of the products and packages before you pay the balance.
